PCD Tools for HPL Machining

HPL material machining

HPL stands for High Pressure Laminate, which is a type of composite material made from layers of kraft paper impregnated with phenolic resin, bonded under high pressure and temperature. The resulting material is a durable, non-porous, and resistant to heat, scratches, and impact.

machining targets

HPL is widely used in commercial and residential applications, such as countertops, cabinets, flooring, wall cladding, partitions, and furniture.

Its versatility, durability, and aesthetic appeal make it a popular choice for architects, interior designers, and homeowners.

The manufacturing process of HPL involves several steps, including the impregnation of kraft paper with phenolic resin, layering of paper sheets, pressing of the laminate under high pressure and temperature, and trimming to the desired size. HPL can also be post-formed or curved using specialized machinery, allowing for a variety of design options.

Machining of HPL involves cutting, drilling, and routing the material to the desired shape and size. Due to its hardness and abrasiveness, HPL requires specialized cutting tools, such as PCD (Polycrystalline Diamond) end mills and PCD drills. The machining process should be carried out with care to prevent chipping or delamination of the laminate.

PCD tools are made from diamond particles bonded to a carbide substrate, providing exceptional hardness and wear resistance.

PCD end mills and drills are commonly used in machining HPL due to the abrasiveness of the material.

PCD Drill for hpl machining

PCD Drill

When machining HPL, PCD end mills and drills offer several advantages over traditional cutting tools. Firstly, they are more durable and can maintain their sharpness for longer periods, reducing the need for frequent tool changes. Additionally, they produce less heat and friction during cutting, reducing the risk of delamination or chipping of the laminate.


PCD Spiral End Mill


When using PCD tools for machining HPL, it is important to consider the specific cutting parameters, such as feed rate, spindle speed, and depth of cut. These parameters will vary depending on the thickness, density, and type of HPL being machined. In general, a lower feed rate and spindle speed is recommended to minimize heat buildup and prevent damage to the tool and workpiece.

Furthermore, it is important to ensure proper tool setup and alignment to prevent vibration or deflection during cutting, especially when relatively small material thickness is about, which can result in poor surface finish or tool breakage.


For more information www.telconpcd.com, [email protected]

In modern technology and the increased demand for high-performance materials in various industries, such as Aerospace, Communications, and Semiconductors,
have led to the use of new materials like CFRP, MMC, CMC, Green Ceramics, Sintered Ceramics, and others.

These materials offer various advantages over traditional materials like metal alloys, such as high strength-to-weight ratio, good electrical and thermal conductivity, and improved durability. However, machining these materials is a challenging task, as they are brittle and prone to cracking, leading to increased tool wear and reduced machining efficiency.

CFRP is used extensively in Aerospace industry to achieve high strength to weight ratio.


CMC (Ceramic Matrix Composite) is used in modern jet engine to produce the heat zone blades improving jet engine efficiency.

Brake disks in modern and sport vehicles are made from MMC (Metal Matrix Composites), in this case, Aluminum matrix with SiC hard particles.

Cell phones enclosures and other communication equip. enclosures are made from Aluminum with high (>8%) Silicon content to achieve strength and durability.

In the semiconductors industry, ceramics like c-Si is used for showerhead parts, SiC is used for cooling elements and Quartz is use as furnace tubes.

In nuclear applications, the use of AlB2 and B4C, is common as a neutron absorber and fuel rods cladding.

PCD (Polycrystalline Diamond) cutting tools have emerged as a solution to these challenges and offer several benefits in the machining of these advanced materials.

PCD cutting tools are made of a diamond layer that is sintered to a carbide substrate, creating a cutting edge that is extremely hard, durable, and abrasive resistant. This makes PCD cutting tools ideal for machining materials like CFRP, MMC, CMC, Ceramics, and nonferrous alloys.

One of the main benefits of using PCD cutting tools in these materials is their ability to achieve high precision and accuracy. The hard and durable cutting edge of PCD tools ensures that the cuts are smooth, reducing the need for secondary operations, and leading to improved dimensional accuracy. This is particularly important in the Aerospace industry, where high precision components are required for complex assemblies and aerospace systems.

PCD Drill commonly used in Aerospace in CFRP and GFRP applications.

Another advantage of using PCD cutting tools is the reduced tool wear. The cutting edge of PCD tools is made of diamond, which is the hardest materials known to man. This means that the cutting edge is highly resistant to abrasion and wear, resulting in longer tool life compared to conventional cutting tools. This translates to reduced downtime for tool replacement, increased machining efficiency, and cost savings.

Drill life comparison in CFRP application between PCD and Tungsten carbide drills. Life difference is almost x20

In the Communications and Semiconductors industries, high surface finish is critical for ensuring optimal performance and reliability of the components. PCD cutting tools can achieve high surface finishes due to their fine grain structure, leading to improved surface quality, and reduced roughness. This is particularly important for semiconductors, where the surface finish affects the performance and reliability of the devices. In addition, semiconductors materials, such as single crystal silicon, Alumina, SiC and Quartz, are extremely hard materials, where only PCD tools can be used with reasonable longevity.


PCD micro-Drill 0.75mm used in Semiconductors, in Single Crystal Silicon showerhead plates drilling.


PCD Multi-flute endmill 2.0mm for machining Hard SiC and TC

PCD 3 FL Spiral endmill 1/4″ for machining green Ceramics and Al-Si enclosures for communication Ind.

In conclusion – PCD cutting tools offer numerous benefits in the machining of advanced materials like CFRP, MMC, CMC, green ceramics, sintered ceramics, etc. They provide high precision, accuracy, and surface finish, while also reducing tool wear and increasing machining efficiency. These benefits make PCD cutting tools a valuable tool in the Aerospace, Communications, and Semiconductors industries, and they are likely to play an increasingly important role in these industries as the demand for advanced materials continues to grow.



Telcon's BHI Screw Removal Kit

Dental implant surgeries are a common and highly effective way to replace missing teeth, but as with any procedure, complications can arise. One of the most frustrating issues dentists face is the failure of screws in the implant, which can lead to prolonged recovery time and unhappy patients. However, Telcon diamond tools’ BHI screw removal kit offers a solution to these problems, making it a must-have for any dental professional.

The kit is specifically designed by Telcon diamond tools to tackle two common screw failures in dental implant surgeries: stuck or damaged screw heads that can’t be opened with a traditional screwdriver and broken screws with part stuck inside the implant. With Telcon diamond tools’ patented and revolutionary product, removing screws can be done in just a few minutes, providing full satisfaction for both the dentist and the patient.


Why Telcon’s BHI Screw Removal Kit is Superior

One of the key advantages of Telcon diamond tools’ screw removal kit is its ease of use. Unlike other kits on the market, Telcon diamond tools’ product is designed to be user-friendly, making it easy for dentists of all skill levels to quickly and effectively remove screws. This means that even in difficult situations, Telcon’s kit can come to the rescue and help fix any screw failures.

Another advantage of Telcon diamond tools’ BHI screw removal kit is its ability to effectively remove screws even in a few minutes. The product is designed to work on 3.3 and 3.75 internal hexagon implant screws, whenever they are stuck or damaged. Other products in the market do not address the problem of stuck/damaged screws and anyhow, using them is more complex and might take an hour or more to overcome the problem, if ever.


Benefits for Patients

Telcon’s BHI screw removal kit not only benefits dentists but also their patients. When a screw fails, it comes with a less-than-ideal outcome of inconvenience of the patient. With Telcon’s BHI screw removal kit, dentists can quickly and easily remove screws in a few minutes, helping patients to recover faster and achieve a better outcome.

Additionally, because the kit is able to remove screws even in difficult situations, it reduces the need for implant extraction and replacement. This means less stress for both the dentist and the patient, making for a more positive experience overall.

In Conclusion

Dental implant surgeries can be a great solution for missing teeth, but when screw failures occur, it can cause frustration for both the dentist and the patient. Telcon diamond tools’ kit offers a solution to these problems, making it a must-have for any dental professional. With its user-friendly design and ability to effectively remove screws even in difficult situations, Telcon’s BHI screw removal kit is a revolutionary product that can help rescue any situation where a screw needs to be removed.

Don’t let screw failures hold you back, elevate your dental toolkit with Telcon’s BHI screw removal kit today and experience the benefits for yourself and your patients.

Click here to purchase the kit

Diamond on Polycrystalline diamond particles

Polycrystalline Diamond also known as PCD is produced synthetically by sintering together many (Poly) diamond particles, usually in the size of 2 to 30 microns of a meter, with a metal binder (mostly Cobalt) at high temperature and high pressure. The PCD material may contain 90-95% diamond particles and the rest is the binder, PCD is commonly used in cutting tools to cut through composite materials and super hard metals for extended tool life as these materials are very taxing on the milling materials.

materials tungsten carbide Diamond particles as part of PCD

Typical characteristics  of PCD:

Hardness – being made from diamond, its hardness is close to pure diamond hardness of 10,000 Hv, however, since it contains metal binder, the hardness will be lower and vary between 6500-7500 Hv.

Wear resistance – it is the second to pure diamond. The hardness of the material allows the ability to withstand wear and long last in any application where abrasive materials are involved. Workpiece material and cutting speed influence on the wear rate. Significant wear rate advantage of PCD vs. Cemented Carbide can be found in machining Composites, MMC, CMC and high silicon Aluminum.

TRS (Transverse Rapture Strength)– PCD is considered a hard material, therefore more brittle and less tough compared to metals. However, PCD materials with different grain sizes, have different TRS. It is evident that PCD material with lower grain size, have higher TRS than PCD with higher grain size.


To emphasize the difference between various materials, let us look at cutting tool materials in reference to their comparative toughness and hardness.

From this diagram, we can conclude that coated carbide tools have the largest amplitude of usages, therefore they represent the majority of cutting tools in worldwide usage.

In addition, PCD is the hardest cutting tool material, however, has the lowest toughness. This is the reason why PCD tools are being used in applications where workpiece material is relatively abrasive and removed chips are in the form of powder (composites, ceramics etc.) and/or require low shear force (Aluminum, Brass, Copper etc.).

To put things into perspective, let’s discuss about different applications, using PCD tools:

Toughness to Hardness graph for processing materials

Using Polycrystalline Diamond in Milling:

Milling operations involve interrupted cutting of the material, where each end mill tooth is engaged with the material and exiting it in one tool revolution. Each time the cutting edge enters the material, the “hammering” effect might damage the cutting edge of the tool. PCD tools perform the best in milling of composites, ceramics, and Aluminum. For example, composites parts, such as CFRP and GFRP in the aerospace are trimmed and finished to final dimension by PCD 2 flutes endmills and spiral PCD endmills. PCD end spiral and multi-flute end mills are used to machine ceramics in green stage, such as SiC, BN and C/SiC. PCD reamers and plungers are used in Al-Si materials in the automotive for engine and gear boxes.

milling tool

PCD milling tool

Using Polycrystalline Diamond in Drilling and Turning:

In drilling and Turning operations, the tool cutting edge has constant contact with the material, unlike milling, therefore the cutting edge is less likely to chip or fracture. The PCD wear rate is low, compared to carbide, allowing for longer tool life and hole diameter consistency. PCD drills can be found in CNC shops in the aerospace, drilling composites materials, such as CFRP, GFRP and MMC.

drill horizontal coated

PCD drilling and boring tools are used in Al-Si materials in the automotive for engine and gear boxes. PCD turning tools are used in composites in the defense industry for missile parts and in the automotive, machining Al-Si car bearing.

special PCD tool

special PCD insert


Feel free to contact us for further information at [email protected].


Drill in Composites

PCD drills are considered high-end cutting tools, due to their rather complex manufacturing process and their higher market price compared to regular Tungsten Carbide drills.
In this ever-evolving composites materials market, the number of applications increase constantly, not only for the traditional aerospace segment, but also for Automotive, Wind turbines, Marine, Infrastructure and sports.
The use of PCD drills in composites is crucial for hole quality, process stability and cost effectiveness.
In this article we will explain why PCD drills are the best option an end user can choose for his composite application

You can divide the manufacturers of composite materials parts, which require hole making, into 3 types: End-users who use mainly PCD drills including regrinding services; End-users who use mainly CVD drills; End-users who use mainly carbide drills.

Tools price Vs. Process cost

While most buying decisions are price driven, there is no argument about end-users with low volume usage of drills and the best option for them probably is to search for the lower priced tool which complies to their requirements. In most of the times, it would be a Tungsten Carbide tool, which considered economical in price.
However, when large number of holes or large number of parts are about, the measurement of tool price only may be misleading. It is advisable in this case to look in a wider perspective.
The cost of cutting tools in an average manufacturing plant may vary between 5-10% of production cost, therefore saving the money on a chipper but less efficient tool is not worthwhile in most cases. The best measurement of tool effectiveness is by checking the entire machining process while measuring the cost of the tool divided by number of meters (in case of an endmill) or number of holes (in case of a drill).
When using CVD drills, the measurement is straight forward, by dividing the price of the tool to the average number of holes it is making. This would be the normal cost of the drill.
In case of using PCD drills, this measurement is not enough, since PCD drills can be resharpened few times and an overall life expectancy and overall number of usages must be measured.
But before we discuss this further, let’s try to remember the differences between Tungsten carbide, PCD tools and CVD diamond coated tools.

PCD Vs CVD Vs Tungsten Carbide

materials tungsten carbide

PCD (Poly Crystalline Diamond) is produced synthetically by sintering together many diamond particles, usually in the size of 2 to 30 microns of a meter, with a metal binder (usually Cobalt) at high temperature and high pressure. The hardness of the PCD is at the range of 6500-7000 Hv.

CVD material

CVD Diamond (Chemical Vapor Deposition) – is a process of
coating Nano diamond particles on a Tungsten carbide substrate (tool) applying a typical layer thickness of 6 to 14 microns of a meter. The hardness of the CVD Diamond is at the range of 8500-9000 Hv.

Tungsten Carbide (TC) is a hard material compound with W and C double the density and stiffness of steel, used as sintered with cobalt as the binder, mostly to produce cutting tools. Typical hardness is 1500-1800 Hv.

contact us

Comparing these 3 tool materials, it is evident that PCD and CVD are much harder than Tungsten Carbide therefore much more wear resistant. There is an advantage to the CVD diamond coating in terms of hardness on the PCD, though much smaller.
When delamination is the failure criteria, CVD diamond drills are likely to perform better than the PCD wafer (segmental) drills due to the superior hardness of the cutting edge in minimizing delamination at the hole exit.
This is one of the major concerns in the drilling of composites in highly engineered parts in the Aerospace.
The TC drill is likely to wear very fast due to much lower hardness, so it creates more deflection and delamination than the PCD and CVD drills. It is known that tool life differences between TC tools and Diamond tools can be up to 25 times in favor of the diamond.

When hole diameter is the failure criteria, then the PCD drill is likely to hold longer than CVD drills. The reason for this is since CVD diamond is a coating implemented on top of TC substrate. When it eventually peels off, it would expose the tungsten carbide underneath and edge wear will accelerate rapidly.
The PCD, on the other hand, is a solid diamond. Wear development rate is rather fast at the very beginning when edge radius develops but then it stagnates for long period of time.
Another example where PCD have an advantage is when drilling a stack material like CFRP/Aluminum, where the exit hole is in the Aluminum. Delamination is a non-issue in this case, therefore PCD drill would be first choice since it will hold hole accuracy longer and can also be reconditioned few times (unlike CVD drills).
Another major advantage of the CVD diamond drill would be design flexibility. The CVD drill is manufactured in 5-6 axis grinding machine to a complete geometrical design and later is being diamond coated, whereas most of PCD drills in the market are based on straight segments which limit the design flexibility.
Design flexibility is critical when building a point geometry to tackle composites.

Wafer PCD vs. Full-nib PCD

Now we must explain the two different types of PCD drills: the Wafer drill and the Full-nib drill.
In the wafer (segmental) drill, PCD segment is in the drill center and drill geometry is built around it, while being limited to its shape and size.

Wafer drill PCD
On a Full-nib PCD drill, on the other hand, the PCD has a cylindrical solid shape on top of the carbide shank, therefore drill point design has no limitations.
Most of hole sizes in composites are in the range of 2.5mm to 8mm in diameter. This is the range of diameters where PCD Full-Nib drills can be most efficiently manufactured and utilized, since larger diamond nibs are quite expensive.

Full nib PCD Drill

The new Helicon Full-nib PCD drill

Telcon has developed the New Helicon Drill for extended tool life, accuracy and repeatability while maintaining delamination-free results.

hole counts

Unlike PCD wafer drill, The Full-nib PCD allows for flexible design. The new Helicon is designed with 2 point-angles with slower, more gradual penetration into the material.
The consequence of that is lower thrust force on the material and much lower delamination and deflection of the composite materials.

Case Study comparing PCD vs. CVD vs. Tungsten Carbide drills:
The application is drilling a CFRP unidirectional material, 5mm in thickness with diameter 4.87mm (.191″).
4 drills were tested:

  1. A tungsten carbide uncoated dagger style drill 4.87mm.
  2. A Helicon PCD Full-nib drill 4.87mm.
  3. A PCD wafer drill 4.87mm.
  4. A CVD diamond drill 4.87mm.
test setup

test setup

Drilling cutting conditions are based on common practice in drilling composites.

RPM Feed mm/min
Tungsten carbide drill 3800 180
PCD Wafer drill 6500 300
PCD Helicon drill 6500 300
CVD diamond drill 6500 300

Test criteria is the size of generated Delamination. Failure occurs when delamination is more than 1mm further from hole circumference.

max allowance
Drilling results were monitored every 200 holes for the diamond drills and every 100 holes for the TC drill. Then, holes were checked and marked for G/NG.
Final test results are gathered in the table and diagram below:

Number of holes until delamination criteria Hole size reduction from 1st to last hole (µ meter)
Tungsten carbide drill 85 25
PCD Wafer drill 760 10
PCD Helicon drill 1730 15
CVD diamond drill 1480 20

Test Hole comparison

It is evident that the Tungsten carbide drill has much lower tool life as expected. The reduction in diameter from 1st to last hole is also the largest.
The Helicon drill has the best tool life while the CVD drill is second. The Wafer drill is approx. 50% in life compared to the Helicon drill. It is noticeable that the CVD drill has higher hole
diameter reduction than the PCD drills.
Cost comparison:
To better emphasize the significance of these results, let us make a cost comparison based on this test:

Tool cost $ Number of resharpening Resharpening cost $ Total cost $ Total number of holes Total cost/hole $
Tungsten Carbide Drill 45 3 15 90 340 0.265
PCD Wafer Drill 181 3 63 370 3040 0.122
PCD Helicon Drill 198 3 69 405 5190 0.078
CVD Diamond Drill 132 N/A N/A 132 1480 0.089

Summary and conclusion:

1. It is shown that PCD Full-nib drill, Helicon, is superior in tool life and normal cost (cost per hole).
2. It is shown that CVD drills are a very good solution when it comes to preventing delamination, although cost per hole is slightly in favor of the Helicon Full-nib drill. However, when hole accuracy is held within thin boundaries, the Full-nib drill outperforms the CVD drill.
3. It is also shown that the use of Tungsten carbide drills cost 3 times more than the use of PCD Full-nib drill, therefore advisable to be used only where there are fewer holes per part or lower number of parts to produce.
4. Setup time is excluded from this comparison, however if to be added, differences would be even higher, since tungsten carbide drills would need much more frequent replacements and will consume more machine idle time.
5. Feed rate comparison is excluded as well, and if considered, the Diamond  drills are 67% faster in table feed, so machine time can be saved.

contact us

drill countersink at work

Some of you, who are in the aerospace industry, are probably familiar with a drill/countersink tool used in CNC manufacturing, to machine both the hole and the chamfer for the rivet head.

Did you know that with some modification, the same concept works also in manual operations? We’re here to tell you about it.

What is a Drill/Countersink tool?

plane is the common use for drill countersink combined work

A Drill/Countersink is a tool used mostly in CNC manufacturing of aerospace parts, with a purpose to machine both the required hole diameter and the relevant chamfer size for the rivet head. The tool can be made from PCD or CVD to be used for Composites. The drill head can be made from carbide and the countersink from PCD, to handle stack materials, such as C/Al or C/Ti.

an elongated drill/countersink

The usage of a Drill/CSK sometimes limited in CNC from various reasons:

  1. It is not worthwhile preparing a jig for every part and machine it in CNC.
  2. In some cases, the drill entrance side, is not the same side the chamfer has to be made.
  3. When large part is about, there are concerns that along the part, you can not achieve the same chamfer size, due to minor part deflections in machining. In this case, drilling is done in CNC and countersinking later in manual operation at the assembly line.


While these circumstances limit the use of Drill/CSK in CNC, in assembly line, when all operations are done manually, the use of such a tools, does not exist so far.


What is the new concept?

Telcon developed a new concept of manual use Drill/CSK tools, which include 3 types of tools. All of them can be used manually with a thread connection to a standard stop-cage.

manual drill countersink


A Carbide Drill/CSK

Designed for C/C.

DKCC series.

A Carbide Drill/countersink Designed for C/C. DKCC series.



Designed for C/C

DKPC series.

A PCD Drill/CSK Designed for C/C DKPC series.


A Carbide Drill/CSK

Designed for C/Al, Al/Al

DKCA series.

C/Al, Al/Al DKCA series. drill countersink

What are the benefits?

  1. Reducing number of operations – saving one or two operations and setups.
  2. Saving hourly costs.
  3. Reducing lead time of part manufacturing.
  4. Improving part quality – hole-chamfer concentricity is improved since both operations are done with the same tool.

contact us

Case study 1 – Composites/Composites:

Need to connect two panels of CFRP, with a thickness of 2.5+3.5mm.

Final hole diameter is 4.5mm with countersink angle of 100°.


Current process steps Improved process steps
Lower panel is drilled in CNC with 3.3mm pilot holes. Lower panel is drilled in CNC with 3.3mm pilot holes.
Upper panel is temporarily glued to the lower panel Upper panel is temporarily glued to the lower panel
A 3.3mm drill is manually used to drill 3.3mm holes also at the upper panel while the lower panel holes guide the way. A stepped Drill/CSK (3.3/4.5/100°) series DKCC is manually used to create the final 4.5mm diameter and the 100° chamfer
A carbide 4.5mm drill is manually used to enlarge holes in both panels. Riveting is used to connect both panels
A PCD countersink is manually used for the chamfer of 100°
Riveting is used to connect both panels

Summary: with the use of Drill/CSK, 2 operations and 2 setups were saved. In these parts there are 80 holes to drill. This means 2×80 = 160 times drilling operations. Practically, the customer is able finishing 6 parts a day instead of 4 parts with the previous process.



Case study 2 – Aluminum/Aluminum:

Need to connect two periphery panels of Aluminum, with a thickness of 1.6+1.8mm.

Final hole diameter is 4.0mm with countersink angle of 100°.


Current process steps Improved process steps
Lower panel is drilled in CNC with 2.5mm pilot holes. Lower panel is drilled in CNC with 2.5mm pilot holes.
Upper panel is temporarily glued to the lower panel Upper panel is temporarily glued to the lower panel
A 2.5mm drill is manually used to drill 2.5mm holes also at the upper panel while the lower panel holes guide the way. A Drill/CSK (4.0/100°) series DKCA is manually used to create the final 4.0mm diameter and the 100° chamfer
A carbide 4.0mm drill is manually used to enlarge holes in both panels. Riveting is used to connect both panels
A PCD countersink is manually used for the chamfer of 100°
Riveting is used to connect both panels

Summary: with the use of Drill/CSK, 2 operations and 2 setups were saved. In these parts there are at least 900 holes to drill only with this diameter. This means 2×900 = 1800 times drilling operations. Practically, the customer is able finishing manual operations on one part in 3 days instead of 5 days with the previous process.

contact us

PCD or Carbide countersink

Both PCD and carbide countersinks are commonly used in assembly and manufacturing processes, but what are the advantages of each type? what is the use case and when will we need to make the choice? in this article we will cover some of these questions in depth.

What is a Countersink tool?

A Countersink (in short, CSK) is a cutting tool with edges tilted to a certain angle to create a chamfer at a certain size. The chamfer is mostly at the end of a hole in a manufactured part. The chamfer holds the head of a connecting element such as a bolt, rivet, or a screw, to have the head of this element align with the part surface.



What are Countersink tool types?

There are multiple applications for Countersink tools, in almost every industry, however we would like to focus on the usage in the aerospace airframe industry.

Countersink is a very common tool in the assembly lines of airplanes, since all body parts are attached and connected with rivets. The head angle of the rivet is 100 or 130 deg mostly and the Countersink tool angle is built accordingly by the Countersink manufacturer. Countersinks can be either with an integral pilot which is a part of the Countersink body, or with an exchangeable pilot, where the pilot is a made separately and inserted to a central hole in the Countersink . The pilot stabilizes and centers the position of the chamfer relative to the existing hole centerline in the part. The Countersinks are being held inside a stop-cage device, which allows setting up the depth of the Countersink penetration, hence the size of the chamfer given in the spec.



What applications with Countersink are at the airframe assembly lines?

There are two main applications for Countersinks, one which involves connecting parts made from Aluminum and second, parts made from FRP (Fiber reinforced plastic). There can be also a combination of both. There is not much difference in the way the Countersink tools are used in these two applications, there is, though, a major difference in the Countersink type. While in Aluminum parts, recommended Countersinks are with tipped carbide segments, on the Composites parts, recommended Countersinks are with PCD tipped segments.


PCD Countersink VS. Carbide Countersink

Understanding the difference between PCD and carbide, can explain some common mistakes end users are making while using the wrong countersink type for their application.

Composite materials are extremely abrasive due to the hard fibers inside their matrix especially in carbon fibers (CFRP). Choosing a carbide tipped CSK for this application is mistake no. 1.

PCD is 3-4 times harder than carbide. This explains the wear resistance advantage of PCD vs. Carbide in cutting composites. PCD tools can outperform a carbide tool by at least 20 times and show consistent quality results over much longer time compared to carbide.

People often compare only tool price and while PCD CSK may cost 2-3 times the price of Carbide CSK, that is mistake no. 2.


When using PCD Countersink vs. Carbide Countersink you would benefit from:

  1. Longer tool life by a factor of 20 at least.
  2. Consistent part quality over much prolonged time.
  3. Fewer setups.
  4. PCD CSK can have the option of resharpening and re-use at least twice.


Let’s compare “apples to apples”:

One PCD Countersink would in average make 1500 holes in CFRP, while carbide will make around 60 holes.

If we consider 2 re-condition cycles for PCD Countersink , that is a total of 4500 holes in one life span of a PCD Countersink.

Carbide Countersink PCD countersink
Average cost, 1/2″ integral countersink, 100deg 35$ 80$


Re-condition cost N/R 2×28$ = 56$
Total Setup cost (in average 5min. to replace a tool and calibrate), average hourly cost of 60$ For 4500 holes, 75 times CSK must be replaced, that is 375 minutes, or 6.25 hours, which ultimately cost 375$ Total of 3 setup cycles, that is 15 minutes


Total tool cost for making 4500 holes 35×75+375 = 3000$ 80+56+15 = 151$
Tool cost/hole 3000/4500 = 0.67$ 151/4500 = 0.033$
Savings/Hole with PCD 95% cost saving!


There should be no doubt now, that PCD Countersinks are much better for using on composites.


Telcon Diamond Ltd. manufactures both types of Countersink tools made from the best PCD and carbide grades.

We can assist with your application – please contact us on:

contact us

As part of the fabrication of dentures it is a common practice to bind yourself with one manufacturer for the Cad/Cam machine and get both the Dental blanks and the Dental Burs in one package, this package is supplied by the manufacturer and can be adequate.

However, in these packages hides a large loss for the dental lab, bringing both the price up and provides redundant elements that may not be needed as part of the package. Many dental labs are reluctant to move from the manufacturer options even if it is an inferior product to the existing options in the market.

Getting the Right Dental tool for the job

Dental milling tools are a great example for this, while the manufacturers mostly sell regular milling tools from solid carbide, in the market exist a vastly superior option: Telcon PCD Dental  tools with much longer lifespan and the ability to keep the cutting edge for much longer periods and under heavy workload, reducing in inaccuracy caused by wear of the cutting edge by a large margin.

Using Telcon patented alternative tools in the Cad/Cam milling machine will get you up to X8 savings per crown compared to existing milling tools provided by the machine manufacturer, and that just in direct tooling costs, the number can radically increase when considering setup time and inaccuracy ratio.

Why Dental labs don’t change the dental burs they use today?

In many cases Labs are reluctant to swap the machine manufacturer as the milling tools supplier, this is caused due to two things:

  • Simplicity: it’s close to home, it’s easy and you already know the supplier…
  • Fear factor: will it annal my warranty? Will the new product fit in the machine?

It’s very easy to see why the Labs are reluctant to swap suppliers, however it’s also very easy to see why the swap is very lucrative! By saving the inherent costs in the process the lab can have more bang for the buck and save thousands of dollars each year.

Why use Telcon dental milling tools?

Telcon dental milling tools are the cream of the crop, the Patented unique tools provide up to X15 more crowns per tool then existing tungsten carbide tools. The tools are very durable and allow high speed processing of many crowns without losing the cutting edge or harming the crown accuracy. In addition, telcon tools are adapted to fit the chucks of Sirona, Amann Girrbach and Zirkonzahn Cad/Cam milling machine.

Telcon tools have a long history of success and performance in very demanding industries such as aerospace industry, Telcon has decided to use this expertise in the Dental milling tools industry to create a vastly superior product that can out preform the existing products in the market by a large margin.


  1. Bur Usage:
    • Applicable materials: Zirconia and PMMA discs only.
    • Cooling conditions: Dry or wet.
    • Bur selection: Refer to machine manufacturer’s standards.
  2. Cutting Conditions:
    • Preset in most CAD/CAM programs.
    • Use tables below if no presets exist.
  3. Bur Information:
    • Table details dimensions, catalog numbers, and compatible machine types.

Table: Bur Dimensions and Cutting Conditions

Material Bur Type Diameter (mm) RPM (Roughing) RPM (Finishing) Table Feed (mm/min) Ap (mm) Ae (mm)
Zirconia Tungsten Carbide 2.5 28,000 1200-1500 0.3 1.25
2.0 35,000 1200-1500 0.3 1.0
1.0 38,000 800-1000 0.1 0.1
0.6 63,000 500-600 0.05 0.05
0.5 64,000 500-600 0.05 0.05
CVD Diamond 2.5 28,000 1200-1500
SDT Diamond 2.5 28,000 1200-1500
PMMA Tungsten Carbide 2.5 32,000 1300-1600 0.3 1.25
2.0 40,000 1300-1600 0.3 1.0
1.0 57,000 700-900 0.1 0.1

Note: Ap (axial depth) and Ae (radial depth) data are missing for some finishing conditions in the PMMA section. Refer to the manufacturer’s recommendations for these values.

Buy now

Semiconductor and PCB tools in semiconductor industry

The process and materials used in Semiconductor manufacturing require high precision and wear resistance, as such the process of manufacturing these tools requires the most precise and resilient micro tools, making the process costly and complex, Telcon in this article reviews the place of Micro PCD Drills in Semiconductors Industry and main wear elements in the Semiconductor manufacturing process and shows how using the right tools for the job, can save both time and money for the manufacturer and of the Semiconductor Showerhead and of wafer holders in the Etching process using Telcon high precision micro PCD tools.

The Nature of Machining ceramic materials

Semiconductor manufacturers use ceramics for their mechanical and environmental stability in highly harsh and corrosive environments. Ceramics are adopted in packaging, where hermeticity, thermal conductivity, and mechanical integrity are highly needed. In communications and sensing, ceramic dielectrics support high rates of data transmission and monitoring. One of the vastly used semiconductors materials is Silicon.



Typical materials in Semiconductor industry

Monocrystal silicon the material for PCB in semiconductor industry and where Micro PCD tools are most needed

One of the most used materials in semiconductors is Monocrystalline silicon (c-Si). It has a crystalline structure, or crystal lattice, as continuous solid with no grain boundaries and with no impurities. It is the material for both silicon wafers and semiconductor processing components to avoid contamination. In addition, this gives monocrystalline silicon an advantage over other materials to reliably deliver desired performance specifications within highly complex devices such as microprocessors, electrodes, gas distribution plates. It can be doped with small amounts of other chemical elements to gain specific semiconductor performance characteristics.



Quartz or Fused Silica (SiO2) coomonly used material in Semiconductor industry

Another typical material in the semiconductors is Quartz or Fused Silica (SiO2). Its high heat resistance and purity allows the usage of quartz in silicon wafer manufacturing processes. Fused quartz plates and discs are needed in the semiconductor industry for the fabrication of boats, pedestals, wafers and wafer carriers, for batch processing equipment .For single wafer processing equipment, plates are used to make windows, gas distribution plates, shower plates, wafer carriers and susceptors. In wet cleaning processes the material is used for tank material. Large plates are also used in Flat panel display manufacturing.




Machining methods for Semiconductor industry materials

Most of semiconductor materials are difficult to machine because of their high hardness and brittleness. For example, monocrystalline silicone hardness is around 1200 Hv, Quartz hardness is around 1100 Hv, Alumina (Al2O3) hardness is 1500 Hv and SiC hardness is 2400 Hv. The limitations of mechanical micromachining in the mentioned materials are a consequence of the high values of cutting forces in relation to the tool strength properties, rapid cutting edges wear, chipping at the hole entry and possible cracks in the workpiece.

Micro holes with diameters below 1000 microns are a typical feature of various semiconductors components. There are few methods for micro drilling in hard ceramics; Laser drilling, EDM drilling and Mechanical drilling. Laser drilling would be effective from 5 to 100 microns. EDM micro drilling would be used in cases where very high ratio of hole depth to hole diameter is required given the workpiece material is conductive. Hole diameters from 300 microns and ratio depth of up to 30, are better mechanically drilled since it is faster and more accurate, therefore it is highly in use for semiconductors components.

Cutting tools solutions – Micro PCD Drills in Semiconductors Industry

Tungsten carbide tools are just too close in hardness to the workpiece materials, therefore wear out immediately. Due to the abrasiveness structure of these materials, also CVD diamond coated tools are not recommended due to rapid peel-off of the coating. Due to material properties as mentioned, machining process can only be made with PCD (Poly Crystalline Diamond) cutting tools. making Micro PCD Drills in Semiconductors Industry the only viable option.

Telcon Diamond Ltd. is one of very small group of tool manufacturers to produce micro PCD tools for the semiconductors industry. There are two groups of tools: Micro PCD drills and Micro PCD end-mills. The machining is carried out utilizing highly sophisticated technology to achieve very accurate and ultrafine cutting edge. The PCD grade in use is suitable for micro tools with ultrafine tool edge integrity. Unlike other PCD cutting tools, these micro PCD tool are featured with full PCD head, whereas tool geometry can be fully flexible and optimized.


Telcon’s micro PCD drills series, MPDR, ranging from 0.4mm up to 2.0mm, are used for instance in semiconductors for drilling very tough materials like monocrystalline silicone and Quartz. The high-performance drills allow drilling thousands of holes before replacement.

telcon Micro PCB drill for machining semiconductor shower heads


The micro PCD end-mills, ball nose (MPBN) and square end (MPEM) design, ranging from 0.5mm to 2.0mm, are used for machining of hard ceramic materials which are common in the semiconductors such as

Zirconia, Quartz, c-Si, Al2O3 and SiC.

Telcon PCB Endmill for milling Wafer placment and very fine milling in Semiconductor industry



Application Example 1 – practical use of Micro PCD Drills in Semiconductors Industry:

Drilling in c-Si wafer, 300mm diameter and 10mm thickness, 800 holes with diameter of 0.45mm and 7mm depth.

The part is a Gas Distributor Plate, used in the etching process of the silicon wafer.

Drill is used in 15,000 RPM and feed rate of 20 mm/min, in pecking cycle of 0.15mm.

The holes are inspected mainly for chipping at the hole entrance.

Typical Telcon drill life is 7000 good holes!

Micro PCD Drills in Semiconductors Industry such as Telcon PCB drill used in manufacturing Semiconductor showerheads


Typical hole structure on monocrystal silicon electrode. Holes: 0.45mm dia. x 7mm depth

semiconductor showerhead for wafer etching process —-> through holes on gas etching semiconductor showerhead done using Micro PCD Drills in Semiconductors Industry —> Hole cross section in Semiconductor showerhead manufacturing




Application Example 2:

Machining of 25mm groove depth in Fused Silica (Quartz) material with 2.0mm micro PCD end mill.

The part is used as a carrier in the various processes of the silicon wafer.

The tool is used in 5,000 RPM and feed rate of 150 mm/min, in a depth of cut 0.05-0.1mm.

The material is inspected for chipping and small cracks.

Typical Telcon tool life is 50 meters minimum.


Telcon micro PCB Endmill used in Wafer holder precise milling process


A typical Quartz ring, 300mm diameter, with internal grooves of 2.0mm width and 25mm depth.

Quartz Wafer carrier in Semiconductor manufacturing process —> close up of wafer holder milling process done with Micro PCD Drills in Semiconductors Industry


For more information on our Micro tools solutions:


Dental crown manufacturing process

Dental crown manufacturing evolves a complex process that takes a few steps, from taking measurements through modeling and milling the crown.
while some of these steps are somewhat fixed our dental milling tools allow up to a 20 times increase in tool life which translate to major reduction in cost and shorter time of production due to reduced handling.
we will cover the process and background to show the best practice and your potential benefits with Telcon PCD dental milling tools.

Buy now

About Dental crowns

What is a dental crown?

A dental crown or bridge is a full or semi artificial tooth. It can be made from several dental restoration materials such as Porcelain, Lithium disilicate, Alumina, Zirconia and Metals. The most common material used for making crowns is Zirconia. It is generally manufactured in soft phase (green state) and later sintered to final hardness and shape. Another common material is PMMA (polymethyl methacrylate) which is a plastic material used for most of the temporary restorations. Dental restorations are being made at the technician lab or at the dentist clinic, requiring multiple process steps, either conventionally, with negative impression plaster mold or with intraoral digital scan and cad-cam machines.


Why would we need a dental crown?

Dental crowns are needed to replace broken or missing teeth from functional and esthetical reasons.  For example, we may have a broken tooth, which requires to be repaired. That can be done with Inlays and Onlays. If a tooth is too damaged to be fixed by a simple filling, an inlay or onlay may be used to repair the tooth.

Why would we need a dental crown

Tooth that got a root canal treatment or severely broken tooth would get a complete crown or bridge with the shape of the normal tooth. The dentist attaches the restoration with special cement for permanent gluing, after milling the broken tooth to a certain shape in order to hold the crown firmly in its place.

A Full crown on top of a shaped tooth

A Full crown on top of a shaped tooth

A completely missing tooth would require either a bridge construction or an implant + crown.

When a bridge is done, the two adjacent teeth are prepared to a stage-like shape and the middle crown is supported by the two external teeth. Alternatively, an implant and abutment can be placed, and the new crown is adjusted accordingly.

When broken or missing tooth occur in the anterior (front) teeth section, the restoration is mainly done from esthetical reason. Functional reasons are more likely when several or all teeth are missing.


How dental crown is made?

In case of crown or bridge covering broken teeth, the teeth must be reduced in size so that the crown or bridge will fit over it properly. In the next stage there are two options;

The conventional way is to use a tray with a silicon material impression, which the patient puts in mouth and bites. After a while the silicon material hardens and can be taken out, consisting the 3D shape of the relevant location. This impression is used later for creating another harder impression model cast of the positive shape to be used for measurements and scanning. The scanning information assist the technician to determine the shape of the new required tooth.

A Model Scanner


A more modern way is to use an intraoral digital scan of the prepared tooth in the mouth which makes the need to take impressions, redundant. The equipment required to perform these scans consists of a hand-held scanning tooth-brush-like stick that houses a miniature imaging system. This is connected to a hardware module that both powers the scanner and receives the digital generated image. This scanning file can be than used in a fabrication lab to eventually produce the crown.

Intraoral digital scanning


The fabrication lab uses the STL file to create in CAD (computer aided design) software the necessary shape of a crown to be mounted on top of the broken tooth or the missing tooth. When the file is ready, the same software turns the CAD file into a CAM (computer aided manufacturing) file to be transmitted to a dedicated 5 axis CNC machine.

In the process of Dental crown manufacturing there are different types of machines, from various manufacturers, such as: Amann Girrbach, Dentsply Sirona, Zirkonzahn and others, each one dictating the shape of the raw material, the dimension of the milling tools and the machining strategy, e.g. cutting speed, feeds, stock removals etc.

A zirconia disc during machining


The milling tools which are traditionally in use during dental crown manufacturing are made from tungsten carbide, capable of machining around 100 crowns (depending on size and shape).

Telcon Diamond Ltd is the first company to present PCD (polycrystalline Diamond) crown machining burs.

Since PCD is 5 times harder than Tungsten carbide, the PCD tools are much wear resistant, therefore life expectancy is 10-15 times more than the Tungsten carbide. In fact, 1500 machined crowns can be achieved on regular basis.

Another advantage is consistent high crown quality over time. While Tungsten carbide tools wear faster and lose their size (diameter) faster, deterioration of crown surface finish and dimensions is a fact. Inconsistent quality such as, mismatch, “wavy” surface and broken thin wall can be seen. The first and the last crowns are not within the same quality. With Telcon’s PCD tools, crown surface quality and dimensions are kept the same for much longer hours.

Telcon’s PCD crown milling burs are designed to be used in three machine platforms – Sirona Inlab MC X5, Zirkonzahn CAD/CAM M systems and Amann Girrbach ceramill mikro 5X.

Just replace your Tungsten carbide burs with Telcon’s PCD burs and press cycle start! https://telconpcd.com/product_cat/dental_tools


After zirconia crowns are manufactured, they should get their final working hardness within a sintering furnace. This process may take between 2 – 8 hours, depending on the hardness levels the lab would like to achieve.

No machining whatsoever is done on the crowns in hard state and the crown is practically ready. If specific coloring is required, then it should be applied prior to sintering.

Telcon Diamond Ltd is the only company who suggest a revolutionary process of machining the zirconia also in the hard state, that is, skipping the sintering process, saving time and material (due to 20% shrinkage in sintering). This machining process is under research and is likely to become productive in the near future.

Want to test our dental milling tools? click blow to order the tools now:

Buy now

Composites materials are commonly consisting of two materials: the fibers and the bonding material. In the layup phase in production of the composites part, layers of composites cloth, are built one on top of the other, either manually or automated in a manufacturer specific fiber direction. These layers constructing the thickness of the final part, must be kept intact, unseparated. Damaged material will be weaker, with a potential probability of part failure. PCD drills are designed and manufactured to prevent this event in composite materials, where both the cutting edge and the PCD coating is radically improving tool life and wear resistance, Keeping the cutting edge sharper for longer period of time.

Machining of composites, with PCD tools or other tools, e.g. drilling, milling etc. might cause damage to the composite materials due to the nature of the cutting action and from various reasons, which we will address here.

Potential failure modes in machining of composites are:

  1. Layer delamination.
  2. Uncut fibers.
  3. Uncut resin.
  4. Spalling/splintering.

The most severe failure mode is layer delamination since it is more likely to occur, it has higher impact on material strength, and it is more difficult to fix.

Drilling operation in composites is widely use since composites parts are connected via riveting, therefore all holes are through holes and there are no threaded holes. Generally, the exit hole is more likely to suffer from delamination of layers when drilling in composite materials due to the tool movement direction and cutting forces applied on the lower layer of the material.


There are few factors which influence the probability of delamination to occur:

  1. Drill geometry.
  2. Drill substrate.
  3. Cutting conditions and process.
  4. Workpiece mounting fixture.

On this article – We will focus on the first two factors.

Drill geometry:

A drill with point angle for designed for metal (118 deg and higher) will likely to cause excessive forces on the drill exit, by tearing the last layers too aggressively and causing separation and delamination around the drilled hole.

A PCD drill with 135deg point angle (for Aluminum)

A sharper point angle drill (like 90deg) will have better results while reducing exit forces. However, angle transition, between the point and the cylindrical portion of the drill creates another built up pressure to the last layers.

A CVD drill with 90deg point angle

Telcon Diamond drills, designed for composites, offer 8 facets point geometry, or double point angle which is longer point structure. The second angle, closer to the drill diameter is quite steep, reducing exit forces. Of course, one must consider the space beneath the part to verify there is enough space for the longer point angle drills.

Telcon’s Fullnib PCD drill with double point angles

Telcon’s CVD drill with double point angles

Drills can be used in CNC machines or manually. While drills presented above are for CNC or ADU (auto drilling unit) usage, drills for composites which are used manually have different shape.

Still, though, the point angle must be sharp, for two reasons, one as discussed before, to reduce cutting forces on drill exit, and the second relates to the manual operation itself. Sharper drill, requires less pressure from the operator, therefore applying less force on the material itself, avoiding delamination issues.

One difference we in manual drills, to CNC drills is the flute helix (spiral) angle. While in CNC, machine has fixed location and rigidity in action, in manual operation spiral drills are very difficult to use to maintain a clear cut, hole concentricity and good surface. Therefore, most of manual drills for composites have straight, or very low spiral flutes.

Telcon’s manual carbide drill/reamer double point angles

Drill substrate:

Composites are being cut cleaner when tool cutting edges are sharp. The removed material flowing on the edge of the tool gradually rounds it and makes it dull. Rounded edge applies more axial forces on the material, causing it to be pushed instead of being cut and sheared.

Therefore, the harder tool substrate is, the higher its wear resistance.

Worn out drill cutting edge

Most common composites drill is made from Tungsten carbide. On a scale of 1 to 10, carbide hardness is 2-3, while PCD or CVD coated is on a scale of 7-8.

It is clear, therefore, that diamond tools can last much longer than carbide tools on composites.

If one wants to consider the options, since diamond tools are more expensive than carbide tools, the right way to compare both is by calculating cost per hole. The added value in tool life of diamond tools compared to carbide tools in composites, is much larger than the price difference.

Telcon’s drills for composites, used in CNC operations, as shown above, are all made from PCD segments or CVD coating, in order to maintain hole quality for longer period. A combination of an efficient geometry with the highest quality substrate, brings better, long lasting drilling results.

Get our drills now

Nature of Thermoplastic composites in Aerospace

This article will explain about the two major composites matrices which are in use in the industry and particularly in the aerospace.

Most composite raw materials are purchased ready to be used by the part manufacturers. There are two major composites resin groups, ready to be used, which require different manufacturing methods; Thermoset matrix and thermoplastic matrix composites.

Thermoplastic composites are usually heated and molded or pressed into a mold to receive their final shape, then cooled and to final part is shape. The process involves only heating and cooling.  The process is rather short and reversible. Since heating must take place immediately for the impregnation process, most of thermoplastic composites process are automatically done, involving in-situ consolidation, either in compression molding, filament winding

Thermoset composites layers are laid one on top of the other manually or automatically to the final part width and then oven-cured under vacuum bag to generate chemical reaction which brings them to their final solidification stage and properties. The process is longer and non-reversible.

the structure of composites

The table below shows major differences between the two composites types:

Thermoset Composites Thermoplastic Composites
Generated during curing
(chemical change)
Generated by heating and cooling of the plastic matrix (physical change)
Non-reversible Reversible
Easier to impregnate the fibers into the matrix in room temperature, Easier to process to final shape, thick to thin walls capabilities. Impregnation can be done only during heating; therefore, reaching to final shape is more complex and costly.
Longer process cycle time due to Oven curing which takes few hours Shorter process cycle time, no curing required, however, higher temperatures are required for the processing
Hard and rigid Tougher and more flexible, therefore higher impact resistance
High fatigue strength Lower Fatigue strength
Higher heat resistance Lower heat resistance
Higher dimensional stability Lower dimensional stability
Used mainly with continuous fibers Used mainly with discontinuous fibers
Non-recyclable Recyclable
Raw material must be stored in a specific environment and has limited shelf life Regular storage conditions, unlimited shelf life
Cannot be welded, must be assembled with rivets and fasteners (adding the need for hole drilling and countersinking) Under specific conditions, can be welded to other thermoplastic part

To date, in Aerospace applications, more than 95% of prepregs are thermoset.

contact us

The nature of thermoset Composites

Thermoset composites have been successfully manufactured for aerospace since the 1960’s, and the knowledge is vast and mature. In addition, highly investment has been put during these years to develop processes, materials, equipment, gigs, training and testing for implementing the thermoset composites in aerospace parts.

Major structures in the Boeing 787, the Airbus A350 and Lockheed Martin F35 almost exclusively thermoset composites. Structural airplane parts such as fuselage, wings, beams, tails and others are made from Thermoset composites.

In the automotive, sports cars, supercars and some mass production cars, like BMW i3, are using thermoset composites.

All the energy windmills blades are made from thermoset composites.

Thermoplastics composites, on the other hand, were firstly used by Airbus on the A340, A380 and later, also on the A350. Up until recently, thermoplastic composites on airplanes have been used only for smaller parts like clips or brackets. This is gradually changing as better materials and processes are being developed while thermoplastic composites are being used in bigger parts in components like the horizontal stabilizer of the Leonardo AW169 helicopter, the rudder and elevators on the empennage of the Gulfstream G650. Additional parts were developed such as the fixed wing leading edge, keel beams, interior components, engine pylons, access doors, aircraft flooring and a variety of molded interior parts.

setting of composites with heat treatment

In fact, thermoplastic composites offer number of important advantages over thermoset:

It has higher degrees of impact toughness. It does not require special storage conditions. It does not need to be cured in autoclave for many hours. Two or more parts can be welded together saving the use of rivet connection (drilling & countersinking).  And, it is more ecological since it can be recycled.

Why you will need high quality tools?

There are disadvantages for thermoplastics, which hold back a greater usage of these materials. The main disadvantages: impregnation of fibers can be done only during heating; therefore, reaching to final shape is more complex and costly. In addition, it has lower dimension stability than thermoset composites and has lower heat resistance.

Due to the nature of aerospace industry working under stringent regulations, it would still take years of investment in research and testing until thermoplastic composites will conquer higher volume of usage as compared to thermoset composites.

Telcon Diamond has developed over the years PCD and CVD solutions for both thermoset and thermoplastics composites. While thermoplastic composites involve less drilling and countersinking, the milling (routing) operation of these materials can be challenging since these parts are more flexible and elastic, therefore milling is less stable and tool geometry must be designed accordingly.



The difference between PCD and CVD

In this article, we’ll try clarifying and shedding more light on a dilemma confronted by many end users of cutting tools to machine composite materials, when they are required to decide which type of tool to use for their application. There are mainly two types of diamond cutting tools for composites: PCD tools, where the cutting edge is built from a PCD segment of a specific size and shape and CVD diamond coated tools, where the tool’s edge is completely built in a grinding operation and later coated with CVD diamond.



PCD (Poly – Crystalline – Diamond) is, unlike single crystalline diamond, produced synthetically by sintering together many (Poly) diamond particles, usually in the size of 2 to 30 microns of a meter, with a metal binder (usually Cobalt) at high temperature and high pressure. The rate is 90-95% diamond particles and the rest is Cobalt.


CVD Diamond

(Chemical Vapor Deposition) is a process of coating Nano diamond particles on a Tungsten carbide substrate applying a layer thickness of 6 to 16 microns of a meter. The tungsten carbide substrate has to contain low cobalt content, such as 6% an d has to go through specific surface treatment. The treatment reduces cobalt content in the outer layer, exposing the diamond edges, in order to create sufficient adhesion between the diamond coating and substrate.

contact us


In the table below, summarized is a comparison between the two types:

CVD and PCD comparison table:

  PCD CVD Diamond coating
Hardness PCD is a composite diamond, 90-95% diamond powder + cobalt binder, therefore lower hardness than CVD. Around 6000 Vickers hardness. CVD is 99% pure diamond, therefore hardness is the highest. Around 8500 Vickers hardness.
Wear resistance Since PCD contains cobalt, the edge is more likely to wear faster, but that occurs until a certain edge radius is reached and remains constant for a longer period. Since CVD is pure diamond coating, the wear resistance is higher, so edge radius is kept sharper for a longer period. However, when coating wears off, since the material beneath is tungsten carbide, edge sharpness deterioration is much faster.
Toughness The cobalt metal binder in the PCD material adds to the strength of the material, as compared to the CVD diamond. Therefore it is likely to have better resistance to chipping in milling operations and in unstable machining conditions. The almost pure diamond layer has lower elasticity and strength, therefore would be more likely to fracture and delaminate than the PCD.
Design PCD tools in the form of wafer segment are limited in geometry to the segment shape. However, when a full nib PCD is used, there are no design limitations. Since CVD tools are first shaped in a grinding operation, there are no geometry design limitations.

Trying to make this comparison practical, let’s discuss different applications in regard to these two diamond tools:

PCD or CVD in Milling operations:

Milling operations involve interrupted cutting of the material, where each end mill tooth is engaged with the material and exiting it in one tool revolution. Each time the cutting edge enters the material, the “hammering” effect damages the cutting edge of the tool. Looking at the table above, PCD tools are more likely to withstand the “hammering” effect in milling. In CVD diamond coated tools, the CVD coating eventually delaminates and only the tungsten carbide substrate is left. In the PCD, even if some fracture occurs, the diamond is solid and therefore keeps the same characteristics. There is a concern, though, about geometry limitations with the PCD. For instance, when a particularly long flute length is required, or when specific tool geometry is required, e.g. porcupine router, the CVD diamond tool has an advantage.


PCD or CVD in Drilling (hole making) operations:

In drilling operations, the cutting edge has constant contact with the material, unlike milling, therefore the cutting edge is less likely to chip or fracture. Taking that into account, with a combination of hardness and sharpness, CVD diamond drills perform better in regard to minimizing the delamination at the hole exit. This is a major concern in the drilling of composites in highly engineered parts, such as Aerospace. When delamination is the failure criteria, there is no doubt that CVD drills outperform PCD drills. However, when hole diameter is the failure criteria, then the PCD drill will “survive” longer than CVD drills.  The reason for this is due to the fact that the CVD diamond is a coating. When it eventually delaminates from the tungsten carbide, edge wear accelerates rapidly. The PCD, on the other hand, as said, is a solid diamond. Wear development rate is almost constant. Another example where PCD may have an advantage is the drilling of stack material like CFRP/Al, where the exit hole is in the Aluminum. Delamination is a non-issue in this case, therefore PCD would be first choice, since it will hold longer and can also be reconditioned a few times. Another advantage of the CVD diamond drill would be design flexibility, while comparing to standard wafer drill, where PCD segment dictates geometry. On a Fullnib PCD drill, however, there is no geometry limitation and design flexibility is the same as in the CVD diamond drill as long as PCD nib height (which is limited) does not create other limitations.

PCD or CVD in Countersinking operations:

While countersinking is considered a manual operation, the countersink body is made from steel, mainly due to the thread connection. Steel cannot be coated with CVD diamond; therefore, most countersinks in the market for composites are PCD. PCD segments are brazed to the steel body of the countersink. Full carbide countersinks which can be coated are rarely seen, due to the fact that grinding the thread on the tungsten carbide body is a complex task.

To Summarize:

The main purpose of this article is helping end users focusing on their goals in a given application. Knowing and understanding your goals, will assist in clarifying tool requirements and choosing the right tool to the application. As it was explained in the article, both PCD and CVD cutting tools have their pros and cons. None of them can fully replace the other. We were not discussing in this article other factors like tool cost, reconditioning, tool diameter limitations and more. Some of these factors will certainly influence our decisions and will be discussed in the following articles. Telcon offers both solutions of PCD and CVD diamond Drills, End Mills, Routers and countersinks for all your composites applications. Feel free to contact us for further information at [email protected].

What are Composite materials?

Composite materials are synthetic materials that are made from two or more material components with different physical or chemical properties that, when combined, produce a material with different (usually better) characteristics than each of the individual components, composite materials are commonly designed to serve specific purpose and the attributes of the material are designed to serve this purpose, for example carbon fiber materials that are designed for light weight and High strength with high brittleness.

Composite materials are in use in various applications in Aerospace, Automotive, Energy, Sports, Construction and more.


Examples of uses for Composite materials

The fundamental advantage of composite materials is higher strength to weight ratio, which brings added value in the aforementioned applications.

In most cases, composite materials are constructed from two main materials: fibers of strong material, such as Glass or Carbon and a polymer matrix material, such as epoxy, which bonds the fibers together in a certain shape.

The table below summarizes the majority of composite material options:

Fibers Polymer Matrix (bond)
Carbon fiber Epoxy
Glass fibers Phenolic
Ceramic fibers Polyimide
Polymer fibers (Kevlar, Polyethylene) Poly-ether-ether-ketone (PEEK)
Tungsten fibers

The two most advanced composite materials in use are Carbon Fibers, also called CFRP (Carbon Fiber Reinforced Polymer) and Glass fibers, also called GFRP.

carbon and glass fiber Composite materials

About the Common types of Composite materials

Mass production of glass strands was accidentally discovered in 1932 when Games Slayter, a researcher at Owens-Illinois, directed a jet of compressed air at a stream of molten glass and produced fibers.

It wasn’t until the late 1950’s that high tensile strength carbon fibers were discovered. Rayon became the first precursor used to create these modern fibers. Ultimately, it was replaced by more effective materials such as polyacrylonitrile  (PAN).

Between the two, GFRP is lighter and stronger, however, more expensive, therefore in use mostly in Aerospace and in luxury and sports cars and professional sport equipment.

Manufacturing process of composite materials involves three main technologies; the manufacturing of the fiber, the manufacturing of the polymers and the manufacturing of the combined composite material itself.

The process for making carbon fibers, which is part chemical and part mechanical involves the use of a precursor (About 90% of the carbon fibers produced are made from polyacrylonitrile, PAN) which is drawn into long strands or fibers and then heated to a very high temperature without allowing it to come in contact with oxygen. Without oxygen, the fiber cannot burn. Instead, the high temperature causes the atoms in the fiber to vibrate violently until most of the non-carbon atoms are expelled. This process is called carbonization and leaves a fiber composed of long, tightly interlocked chains of carbon atoms with only a few non-carbon atoms remaining.

contact us

It’s all in the fiber materials

Fiber reinforced composite materials can be divided into two main categories normally referred to as short fiber-reinforced materials and continuous fiber-reinforced materials.

Continuous reinforced materials will often constitute a layered or laminated structure. The woven and continuous fiber styles are typically available in a variety of forms, being pre-impregnated with the given matrix (resin), dry, uni-directional tapes of various widths, plain weave, harness satins, braided, and stitched.

The short and long fibers are typically employed in compression molding and sheet molding operations. These come in the form of flakes, chips, and random mate (which can also be made from a continuous fiber laid in random fashion until the desired thickness of the ply / laminate is achieved).

the fiber structure in composite materials

In the next article we will discuss different manufacturing methods of composite materials, their pros and cons and their use in the industry.

More info

Diamond is a solid form of the element carbon with its atoms arranged in a crystal structure called diamond cubic.

Why do we use it diamond

Why do we use it diamond

Typically, natural diamonds age for between 1 billion and 3.5 billion years. Most were formed at depths between 150 and 250 kilometers in the Earth’s mantle. Some have come from depths of as much as 800 kilometers under high pressure and temperatures, where carbon-containing fluids dissolved minerals and replaced them with diamonds. Much more recently (tens to hundreds of million years ago), they were carried to the surface in volcanic eruptions and deposited in igneous rocks known as kimberlites.

Diamonds have the highest hardness and thermal conductivity of any natural material.

See the diagram below which emphasizes the level of hardness of diamond in comparison to other materials. The material with the next level of hardness is CBN which is less than half as hard as the Diamond.

contact us

Why do we use it diamond

Hardness is a fundamental property of a material to resist a force applied causing it to deform. Another interpretation of the diamond hardness would be higher wear resistance. It can be easily understood that when diamond is in abrasive contact with another material, the diamond would remove much more stock from the other material, than would be removed from the diamond itself.

Clearly, due to higher hardness, diamond applications can be seen in the cutting tools industry.  Diamonds are used in grinding wheels to grind hard metals, such as tungsten carbide or to cut and shape granite. Diamonds are being used as a cutting tool edge for the machining of non-ferrous abrasive materials, such as composite materials, hard ceramics, high silicone aluminum etc. Diamonds are also being used as a cutting edge in the road-header on excavating machines for roads, tunnels and mining.

Why do we use it diamond

The second advantage of the diamond as a cutting tool material is the thermal conductivity.

During machining, the cutting forces generate heat. The heat is distributed among 3 elements: the workpiece, the cutting tool and the removed material chips.

The high thermal conductivity of the diamond will ensure that large amounts of heat energy is dissipated in the tool itself and less to the workpiece. This protects the workpiece from thermal shock or deformation; this is mandatory, for instance, when machining carbon fiber reinforced plastic (CFRP). A higher heat level in the material might cause melting of the resin material while deteriorating the composite material’s mechanical properties.

Telcon has been manufacturing in-house cutting tools for more than 35 years and gained vast experience and expertise in the manufacture of Diamond PCD tools and solutions for various applications in the machining of composite materials. All cutting tool solutions (PCD drills, CVD drills, PCD end mills and CVD routers or PCD countersinks) are high quality and high performance, providing long tool life with non-delamination and non-bur issues.

What are the differences between real and synthetic diamonds

The main difference between real diamonds and synthetic diamonds is that, real diamonds are mined and synthetic diamonds are created in the laboratory.

Natural Diamonds are formed inside the earth mantle over millions of years at high temperatures and depth. Diamond is made of carbon and has a crystal structure.

Synthetic diamonds also known as “lab grown”, are not mined but are created in the laboratory. These diamonds are made from carbon and even have the same physical properties and chemical composition as natural diamonds. They are made by HPHT (High-Pressure High-temperature) or through commonly used CVD (Chemical Vapor deposition). They are designed to look like real diamonds and have the same characteristics.

The uses of Synthetic diamonds

Synthetic diamonds are lower priced compared to natural diamonds and therefore are used in many industrial applications.

One of these applications is PCD – Poly Crystalline Diamond. PCD is a synthetic diamond produced by sintering together selected diamond particles with a metal matrix at high temperature and high pressure.

The polycrystalline form is ‘isotropic’ – exhibiting uniform properties in all directions. The varying orientation of the constituent micron-sized synthetic diamond grains also provides a greater resistance to cleavage and PCD is therefore, a stronger material. PCD can be machined in electric-discharge machining (EDM) process due to conductive metal content, mostly cobalt. Still, diamond content of the PCD is 90-95%.

What we do with synthetic diamonds

In Telcon, we machine most of the PCD tools in Erosion (EDM) technology, which is applied in wire-cut EDM and disc shape EDM. Among our diamond cutting tools solutions, you can find: diamond drill bits, diamond countersinks and diamond end-mills. In each of these tool categories, you can find both PCD and CVD solutions. For example, you may find PCD drills and CVD drills, PCD end-mills and CVD end-mills for various applications.

Telcon Diamond Ltd. is a world leading manufacturer of Diamond PCD and CVD cutting tools for the machining of composite materials: CFRP, GFRP, MMC, CMC and hard ceramics. TELCON produces a wide range of tools used by many of the world’s leaders in the field including Boeing, Airbus, Lockheed-Martin, Spirit, ATK, Embraer, Denel, ELBIT and IAI. Telcon’s tools include: PCD tipped Drills, CVD diamond drills, Carbide drills, PCD Countersinks, Carbide tipped Countersinks, PCD tipped End Mills and CVD diamond End Mills and Carbide End Mills.

TELCON possesses the most advanced Grinding, and EDM machines and state of the art Quality control equipment. TELCON’s vacuum brazing equipment is highly controlled to ensure repeatability and reproducibility of brazing operation. TELCON uses world class PCD and carbide grades and CVD coatings. In addition to tools manufacturing, Telcon operating reconditioning services for PCD and carbide tools.

In stock Call Now
